ahk-mode and Updating To AutoHotKey Version 2

I have now managed to set up my external USB numeric keypad on Linux using kmonad which lets me use any regular plugged-in number keypad as a shortcut tool for my digital art.

This comes in very handy when painting in Krita and ArtRage (through Wine) and maybe one day I will expand this functionality to GIMP when version 3.0 comes out!

I would like the same keymapping functionality to be reflected on Windows (as ArtRage is fundamentally a Windows application). Technically kmonad should work but I’m going to use AutoHotKey as I’m much more familiar with it.

I have a problem though, my old autohotkey scripts don’t work with the latest version of AutoHotKey (version 2). On further investigation it seems that version 2 is a significant update and includes the simplification and shift of the syntax.

Well I guess I had better update my scripts then!.

On Windows by default an ahk extension offers to open notepad which initially I did as I thought the changes would be simple enough and actually notepad isn’t too bad these days what with the multiple tabs, dark mode and even multiple undos!. However I quickly became frustrated with the lack of syntax highlighting / indenting e.t.c. I have used a specific ahk editor in the past, something like SciTE4AutoHotkey but this time I thought I would break out emacs and see what it had to offer.

Initially loading the ahk script started fundamental mode and of course had no syntax highlighting. Running list-packages and then a quick search for AutoHotkey brought up the only package available, which was ahk-mode. This package seems pretty straightforward and although it was last updated in 2016 (so won’t cater too well with the AutoHotkey v2 shift in syntax) the syntax highlighting, commenting and indenting were just fine enough for me. It also seems to be well integrated with company-mode and although I’m not a great fan of company-mode in general in this case it might actually be useful.

I was now able to comfortably convert my scripts to AutoHotKey v2, for example:

version 1

#IfWinActive, ahk_class ArtRage 3
NumpadDiv:: ^z
NumpadMult:: ^y
NumpadHome::Shift
NumpadUp:: Alt
NumpadLeft:: Space
NumpadRight::
GetKeyState, state, h
if state = D
    Send {h up}
else
    Send {h down}
return
NumpadEnd:: Control
NumpadPgDn:: RButton

version 2

#HotIf WinActive("ahk_class ArtRage 3")
NumpadDiv:: ^z
NumpadMult:: ^y
NumpadHome::Shift
NumpadUp:: Alt
NumpadLeft:: Space
NumpadRight::
{
if GetKeyState("h")
    Send "{h up}"
else
    Send "{h down}"
}
NumpadEnd:: Control
NumpadPgDn:: RButton

While I was in amongst the scripts I decided to add in something extra and that is to map the Capslock key to the Control key; a not uncommon mapping for a regular emacs user.

So I added in the following line and plonked the script into the Windows startup folder:

Capslock::Control
